TOPICS to be Covered :-

  • Understanding of schematics Diagram on the live practical Motherboard and its important Voltage and signals.

  • BIOS ME region Cleaning including CSME & TXE region (6th, 7th, 8th, 9th gen).

  • ALL CHARGING IC's ( Bq24725/Bq24707A ,Bq24735 Bq24745, Bq24751etc) working, Internal logic, Schematics and Troubleshooting of various Charging problem.

  • ALL 3.3/5 V Buck regulator IC's (TPS51225 TPS51223, RT8205A/B/C, RT8206A/B, NB670 etc.) working , internal logic, schematics and Troubleshooting .

  • Power-On sequence of ALL generations With SOC(system on chip) Structure Motherboard. With different states (S0, S3, S4, S5, G2, G3).

  • Feedback voltage, MODE, TRIP, I2C, SMBus, LPC, PCI Signal functions Logic.

  • Various sections including S/B section, Charging section, RTC section, VGA CORE section, RAM section, LVDS section etc Signal, Voltage CLOCK and DATA description.

  • All signals working in schematics e.g - PLTRST#, RSMRST#, VCCRTC, SRTRST#, RTC SUSCLK, X1 & X2, INTRUDER#, INTVRMEN, SYS_ON, RUN_ON, DDR_PWR_OK, VGA_OK, S_PGOOD, RAMRST, SUSP#, 51ON etc.

  • Switching of OP-Amp (Comparator), Diode, MOSFET( E-MOS, D-MOS, C-MOS), Transistor (BJT), in schematics.

  • Graphic to non-graphic conversion and ASUS onboard RAM disable method.

  • Learn the concept and be an EXPERT don't opt for HIT and TRIAL.


Who are in extremely love with eco friendly system..

LAPTOP REPAIRING TRAINING VIDEO COURSE SPECIAL OFFER

1. Complete Laptop Repairing Training With 100+ VIDEOS of 200 hours.
2. MacBook Repair Training LEVEL-4.
3. FREE BIOS, Schematics & Guidance on Faults for Lifetime.
4. Master Online Live Query Class FREE with this VIDEO Course.

CALL NOW - 9871145066, 9031240767

Fill the Form & Subscribe Now

Get a free Estimate
